Tiger G-Series | 3.2T Electric Cushion Tire Forklift | 48V AC Power
Tiger G-Series | 3.2T Electric Cushion Tire Forklift | 48V AC Power
Regular price
$39,999.99 CAD
Regular price
Sale price
$39,999.99 CAD
Shipping calculated at checkout.
Couldn't load pickup availability
Tiger G-Series Electric Cushion
Rated Capacity 3,200 kg / 7,050 lbs
Max Lift Height 4.7 m / 185 in
System Power 48V AC Electric
Tiger G-Series | 3.2T Electric Cushion | Tight-Space Leader
Model CPD32-C. Engineered for indoor high-density warehousing, combining a powerful 3,200 kg capacity with a smooth cushion tire setup for the tightest turning radius in its class.
Warehouse Maneuverability & Efficiency
Ultra-Tight Turning
A compact 80.2-inch turning radius allows the CPD32C to navigate narrow aisles that traditional pneumatic forklifts simply cannot reach.
ZAPI AC Control
Equipped with dual ZAPI MOSFET controllers for travel and lifting, providing programmable speed and regenerative braking to maximize battery life.
Operator Ergonomics
Enhanced foot room, an enlarged entry step, and an arc-shaped overhead guard provide superior visibility and comfort for full-shift operations.
CPD32C Technical Specifications
Rated Capacity3,200 kg (7,050 lbs)
Power System48V AC Electric
Travel Speed (Laden)17 km/h (10.6 mph)
Turning Radius2,037 mm (80.2 in)
Service Weight5,265 kg (11,597 lbs)
Drive Motor8.4 kW AC
Lifting Motor16.5 kW AC
Tire TypeSmooth Cushion
Technical & Support Resources
Full Life-Cycle Support
The CPD32C is the ideal indoor powerhouse for Ontario logistics. We provide full technical service, parts, and battery support from our Scarborough and Calgary facilities.
